SAS 130

SAS 130 is a suspended metal ceiling system with lay-in tiles. It’s available with either a flush or tegular grid finish, offering a clean and modern aesthetic. This makes it a popular choice for commercial offices, labs and data centres.

SAS 130 tiles are lay-in by design, allowing easy access to the ceiling void. No specialist tools are required to remove or replace tiles, which simplifies ongoing maintenance, servicing or inspection of services above the ceiling.

Progressive Materials supplies SAS 130 with a variety of grid types:

• Alugrid-Q, Alugrid-P, and Cleanseal for a flush finish
• Tee Grid T15 and T24 for a tegular effect
• Each grid type supports different module sizes and tile depths, letting you tailor the ceiling to your project’s design intent and functional needs.

The standard module sizes are 500 x 500mm, 600 x 600mm and 750 x 750mm. Tile thicknesses typically range from 8mm, 16mm to 19mm, depending on acoustic and structural requirements. Tile sizes are slightly smaller than the module size to allow easy installation and access.

Yes. SAS 130 tiles can be pre-formed with apertures during manufacturing to accommodate lighting, sprinklers, air diffusers and other ceiling-mounted services. These apertures are post-painted for a clean finish that matches the rest of the system.

SAS 130 is available in all standard Progressive Materials finishes. Bespoke finishes can be specified if required. The most common perforation patterns include 1522, 1820, and 2516, with others available on request. Perforations are typically paired with acoustic pads for sound control.

SAS 130 supports a range of acoustic treatments. Standard options include 8mm, 16mm, or 19mm mineral wool pads (80kg/m³ density) with black tissue facing, foil backing and sides. This provides sound absorption ratings between Class A–D and insulation performance from 15–45dB, depending on the configuration.

Yes. The Cleanseal Alugrid-P option creates an airtight seal between the tile and grid, preventing dust ingress. This is ideal for controlled environments like labs or data centres. Additionally, the system allows for easy relocation of partitions and hanging of signage using its M6 thread form.

Tile weights vary based on thickness:

• 8mm tiles weigh approximately 5kg/m²
• 16mm tiles weigh around 7.5kg/m²
• 19mm tiles weigh up to 10.75kg/m²

The system can also support additional point or distributed loads up to 3kg, but for heavier items, an independent suspension should be used.

SAS 130 is a versatile solution suited to commercial offices, education spaces, data centres and laboratories. Its ease of access, acoustic performance and seamless integration with services make it a practical choice for both new builds and refurbishments.

Yes. Progressive Materials can work with architects and designers to create bespoke modules or shaped tiles for project-specific requirements. Their SAS Plus design service allows you to collaborate directly with the in-house technical team.

The SAS 130 system is designed for longevity. When installed correctly with full system components, it comes with a 25-year life expectancy. This includes the grid, tiles, acoustic backing and suspension fixings.
